LED:CREE 1512 COB LED
Material:12# Die-casting Aluminium housing+8mm Tempering glass+316 Stainless cover
LED Power:24-30W
Lens angle: 18/24°/38°/60°
Input Voltage: 24VDC ;120/240V AC
CCT:2700K-6500K
Size:182*167MM
Cut out:165MM
IP rate:IP67
Housing: 12#Die-casting powder coated aluminum.T=60-80um. Adhesion of ISO class 1/ASTM class 48
Front Cover: 316# stainless steel---Hard Chromeplated
Glass: Tempered glass.T=10mm
Lens: Optical lens, efficiency≥90%
LED Driver: Constant voltage input, Constant current output
Cable Gland: IP68 copper and nickel coated
Gasket: Tooling shaped seal
Mounting Sleeve: PVC
Working Temperature: -20 to 40℃
Power Cable: H05RN-F 2X1.0mm² L=0.5m(low voltage)
H05RN-F 3X0.75mm² L=0.5m(high voltage) MEANWELL DRIVER
H05RN-F 4X0.75mm² L=0.5m(RGB)
Dimmable : DALI Traic PWM 1-10V
