Power:1W~10W
LED:CREE
CRI: 80 / 90
SDCM: 3 / 5
CCT: 2700K / 3000K / 4000K / 5700K/RGB 3in1/RGBW 4in1
Control: Remote / On-Off
Input Voltage:DC24V/AC240V
Dimming: DALI / DMX512 / 0-10V / 1-10V / Triac
Beam Angle: 1/2/4 Side Emitting Holes
Material: CNC 6063# aluminum
Waterproof: IP67
Certification: CE EMC LVD, ROHS, IP67 etc.
Warranty: 3-5 Years/
| Model No.: | Power | LED QTY | LED Color | Beam Angle | Input Volt. |
| BL-SIG800305 | 5-7W | 3PCS | 3000K/4000K /5000K/5700K | 1/2/4 Side Emitting Holes | AC220V |
| BL-SIG800306 | DC24V | ||||
| BL-SIG800307 | RGBW 4in1 DMX512 | DC24V |
Front Cover:Aluminum/Stainless steel SUS304#
Housing: 12#Die-casting gray powder coated aluminum.
T=60-80um.Adhesion of ISO class 1/ASTM class 4B high temperature painting.
Driver:Constant voltage input.Constant current output.
Glass:Step tempered glass.
Dimmable: Triac/Dali/1-10V/PWM/DMX512.
Power Cable:H05RN-F 2×1.0mm2 L=0.5m(low voltage).
H05RN-F 3×1.0mm² L=0.5m(high voltage)
H05RN-F 2×1.0+F3×0.5mm² power cable L=0.5m(DC24V DMX512)
Working Temperature:-20 to 40°C.
